S3 PRO Specifications
| What’s in the Box? |
| S3 Pro × 1 | USB-A adapter × 1 |
| Warranty card × 1 | User manual × 1 |
|
Technical Specifications
|
| Dimensions | 20*10*90mm |
| Net Weight | Approximately 6g |
| MQA Support | X8 |
| Sampling Rate Indicator Light | Supported |
| D/A Chip | ESS ES9281C PRO |
| Sampling Frequency | Up to 32Bit/384kHz |
| DSD | Up to 128 |
| Output | Single-ended 3.5mm headphone port |
| Total Harmonic Distortion + Noise | 0.0008% |
| Signal-to-Noise Ratio | 117dB |
| Channel Separation | 70dB |
| Frequency Response | 20Hz-40kHz (±0.1dB) |
| Output Power | LR 55mW@32Ω 3.5mm SE |
| Power Connector | Type-C |
| Supported Systems | Windows 10, Mac OS, iPad OS, Android, iOS or newer systems. (For iOS users, the Lightning OTG cable has to be purchased separately) |
How to Use
